Do all bath taps fit all baths?

Do all bath taps fit all baths?

Do all bath taps fit all baths?

No, not all taps will be a suitable fit for all baths. ... In the case of freestanding baths, for instance, the design of the tub (without tap holes) will usually mean you would have to opt for freestanding taps or a wall-mounted tub filler.

Are all bath tap holes the same size?

Not all taps and countertop basins will be the same size, so you'll want to make sure that there is adequate space from the top of your countertop basin to where the spout exits on the tap. ... Always check the dimensions of the tap you're buying, as well as the area that you're fitting it in.

Are all taps standard size?

Most taps in the UK are said to be a standard size, but it's worth remembering that the size refers to the way in which the tap fits onto the pipes rather than the size of the taps themselves (basin taps being 1/2" and bath taps having 3/4" threads).

What size taps for bath?

Measuring BSP Sizes
BSP SizeDiameter of the thread (mm)Typical products you might find
1/2"20.9Shower hose, valves that screw into sink or basin taps, the rigid tails on basin taps, UK flexitail connectors
3/4"26.4Bath tap rigid tails, valves that fit into bath taps
1"33.2
1.25"41.9Basin wastes

Are tap fittings universal?

There is no universal standard for which water supply goes on which side of the unit; however by almost universal practice in the UK: In the North, the hot water goes to the tap on the right of the unit while in the South, it goes on the left.

Can you change taps on a bath?

Unscrew the nut from the bottom of the tap and place the tap into the hole in the bath. Ensure it's at 90 degrees to the rim of the bath. Reach under the tap hole and screw the nut back on by hand. Once the bath tap is in the correct position, take the tap spanner and tighten the nut, take care not to damage the bath.

Are bath tap holes standard?

All contemporarily manufactured traditional bath taps, fillers and bath shower mixers expect 2 tap holes with the distance between the holes centres being 180mm.

Are all tap holes the same?

British Standard Pipe 1/2" and 3/4" threads have been standard on taps since at least (I believe) the 1920s and yet for some inexplicable reason, basin and bath manufacturers like to make holes for them up to 3/8" diameter bigger than the threads.

What size is a standard tap fitting?

Tap backnuts typically measure either 27mm or 32mm AF (across flats), though they are more often described as being either 1/2 inch or 3/4 inch. The imperial measurements used to refer to the internal diameter of the threaded pipe they attach to, though this is no longer the case.

How do I know what size my tap is?

As a rule of thumb, for Metric threads, the tapping drill can be calculated by subtracting the pitch from the diameter of the thread. eg for an M5x0. 75 thread the tapping drill is 5-0.75mm = 4.25mm. For Imperial (inch) threads the tapping drill size is calculated in the same way, diameter minus pitch.

What's the best way to fit a bath tap?

  • Step 1. Start by laying down a strip of masking tape along the tap end of your bath. Step 2. With the help of a tape measure, mark the centre of the overflow and using this as a guide, measure the position of the tap holes. If you’re using a bath mixer tap, use the width as your guide for fitting.

What are the different types of shower taps?

  • They mainly fall into 2 broad categories: Mixer taps—1 tap which combines both hot and cold water. These sometimes include a shower fixture too, known as a bath shower mixer tap. There are other, less common bath tap options available, including freestanding taps, wall mounted taps and valve-operated bath fillers.

Which is better a bath mixer or basin tap?

  • The Wye bath mixer from Orchard Bathrooms is a good example of a contemporary bath mixer tap A bath mixer tap is larger than a basin mixer tap as it’s required to deliver a very large volume of water quickly in order to fill your bath. A bath shower mixer tap gives you the added option of switching the flow to a handheld shower.

Can a wall mounted tap be installed in a bathroom?

  • As the name suggests, these our wall mounted taps are fitted to the wall of your bathroom with the pipework hidden behind. They require more work to install, but can create a beautifully clean and contemporary look. These are a good choice for freestanding baths that sit against a wall.
