BS 7671 requires most if not all circuits in domestic premises to be RCD-protected. ... Separate RCD protection is not necessarily required for each circuit of an installation but, in order to minimize the likelihood and consequences of tripping, a single ('front end') RCD should not be used to protect all the circuits.

What circuits need an RCD?

In future, all final sub-circuits in residential dwellings must be RCD protected. No exceptions. For non-residential, final sub-circuits up to 32A capacity supplying socket outlets must be 30mA RCD protected. Hard-wired equipment circuits of this capacity should be.

Does 18th edition need surge protection?

Surge protection devices (SPD) are a requirement under the 18th Edition of the Wiring Regulations and essential in protecting equipment from damage.

Will all installations have to comply with the 18th edition even if they were installed before this edition was in force?

The 18th Edition does say “Existing installations that have been installed in accordance with earlier editions of the regulations may not comply with this edition in every respect. This does not necessarily mean that they are unsafe for continued use or require upgrading”. BE

When did RCDs become mandatory UK?

The UK standard for safety – Since July 2008 virtually all circuits in new or rewired homes have been required to include an RCD under the latest edition of BS 7671.

Are Rcbos mandatory?

RCBO's are a more expensive alternative to RCD's (but have advantages), and are currently not a Requirement. BE

What requires RCD protection?

RCDs protect humans against electrocution in a way that fuses and circuit breakers do not. ... If you have a new circuit installed, or a circuit is substantially modified, you may be required to have an RCD fitted under the Building Regulations (Part P) or BS7671 wiring regulations. This is a legal requirement.

When should a RCD be used?

An RCD is a sensitive safety device that switches off electricity automatically if there is a fault. An RCD is designed to protect against the risks of electrocution and fire caused by earth faults.

Is surge protection required by code?

Code Change Summary: New code section. Surge protection is now required for all dwelling unit services. In the 2020 NEC, a Type 1 or Type 2 surge protective device (SPD) will be required for dwelling unit services. ... Additionally, an SPD will be required when an existing service is replaced.

Is surge protection necessary?

Without a surge protector, a power spike or power surge could shorten the life of your computer, wipe out all of your data, or even completely destroy your system. In fact, you should use a surge protector with any high-end electronic device. BE

When does a lighting circuit need RCD protection?

  • (See 314 Division of Installation). Domestic Lighting Circuits must now incorporate RCD protection <30 mA – see Regulation 411.3.4. Consider any earth leakage current likely to occur in normal operation, to reduce the chance of unwanted tripping. Examples are given in Table 1.

When does an AC socket need a RCD?

  • With the 18th Edition, Regulation 411.3.3 requires all socket-outlets in AC systems rated up to and including 32 A to be protected by a 30 mA RCD, the only exception being for installations other than in dwellings, where a documented risk assessment determines RCD protection is...

Where to discuss RCD protection on 3 phase sockets?

  • Discuss RCD protection on 3 phase sockets/18th edition in the Electrical Forum area at ElectriciansForums.net Ive recently watched some short online videos from the NICEIC which talks about some of the changes that will be incorporated in the 18th edition.

When was RCD protection for socket-outlets published?

  • When Amendment No. :2008 was published in 2015, we reported on changes to RCD protection for socket-outlets in Regulation 411.3.3, with socket-outlets in AC systems rated up to and including 20 A requiring RCD protection unless a risk assessment stated otherwise.
